| Collaborative content caching optimization in UAV-assisted internet of vehicle based on NOMA |
Yiwei ZHANG( ),Xin CUI*( ),Qinghui ZHAO,Yan CHEN |
| School of Computer Science and Technology, Shandong University of Technology, Zibo 255049, China |
|
|
|
Abstract A UAV-swarm-enabled collaborative content caching scheme based on non-orthogonal multiple access (NOMA) was proposed in order to address the communication requirement of computation-intensive and latency-sensitive service in highly dynamic internet of vehicle (IoV) scenario. NOMA technology was integrated to achieve spectrum sharing among multiple vehicle by deploying UAV swarm as edge node. A K-Means++ based dynamic clustering mechanism was designed to periodically partition vehicle cluster and optimize the deployment location of UAV cluster head. A graph convolutional network (GCN) was constructed for the UAV swarm network in order to aggregate the topological relationship, caching status and content popularity feature through a dynamic adjacency matrix. Then the capability of cross-node information sharing was enhanced. The cooperative caching problem was formulated as a decentralized partially observable Markov decision process (Dec-POMDP). An attention mechanism was introduced into the Qmix deep reinforcement learning algorithm. The attention mechanism was utilized to perform weighted fusion of neighboring UAV state in order to maximize the long-term cache hit rate. The simulation results showed that NOMA achieved nearly 60% improvement in latency and throughput performance compared with traditional orthogonal multiple access (OMA). The proposed scheme outperformed other caching schemes across various vehicle density scenario, showing enhancement in key performance metrics such as cache hit rate, average content retrieval latency and energy consumption. The efficiency and robustness of the proposed scheme in dynamic IoV environment were validated.
|
|
Received: 09 June 2025
Published: 06 May 2026
|
|
|
| Fund: 科技博士项目基金资助项目(4041422007). |
|
Corresponding Authors:
Xin CUI
E-mail: zhangyiwei1014@163.com;cx@sdut.edu.cn
|
无人机辅助车联网NOMA协同缓存优化
针对车联网(IoV)高动态场景下计算密集与延迟敏感型业务的通信需求,提出基于非正交多址接入(NOMA)的无人机集群协作内容缓存方案. 引入无人机集群作为边缘节点,结合NOMA技术实现多车辆频谱共享,设计基于K-Means++的动态分簇机制以周期性划分车辆集群,优化无人机簇头的部署位置. 对无人机集群网构建图卷积网络(GCN),通过动态邻接矩阵聚合无人机集群的拓扑关系、缓存状态及内容流行度特征,增强跨节点信息共享能力. 将协同缓存问题建模为分散式部分可观测马尔可夫决策过程(Dec-POMDP),把注意力机制引入Qmix深度强化学习算法,利用注意力机制加权融合邻域无人机状态,实现长期缓存命中率最大化. 仿真结果表明,与传统正交多址接入(OMA)相比,NOMA在时延和吞吐量性能上提高了近60%,所提方案相较于其他缓存方案,在不同车辆密度场景下,缓存命中率、平均内容检索时延及能耗等性能指标均有所提高,验证了所提方案在动态车联网环境下的高效性与鲁棒性.
关键词:
内容缓存,
非正交多址接入(NOMA),
车联网,
移动边缘计算,
深度强化学习算法,
图卷积网络
|
|
| [1] |
GARCIA M H C, MOLINA-GALAN A, BOBAN M, et al A tutorial on 5G NR V2X communications[J]. IEEE Communications Surveys and Tutorials, 2021, 23 (3): 1972- 2026
doi: 10.1109/COMST.2021.3057017
|
|
|
| [2] |
SHI J, DU J, SHEN Y, et al DRL-based V2V computation offloading for blockchain-enabled vehicular networks[J]. IEEE Transactions on Mobile Computing, 2023, 22 (7): 3882- 3897
doi: 10.1109/TMC.2022.3153346
|
|
|
| [3] |
JIANG H, DAI X, XIAO Z, et al Joint task offloading and resource allocation for energy-constrained mobile edge computing[J]. IEEE Transactions on Mobile Computing, 2023, 22 (7): 4000- 4015
doi: 10.1109/TMC.2022.3150432
|
|
|
| [4] |
WU H, JIN J, MA H, et al Federation-based deep reinforcement learning cooperative cache in vehicular edge networks[J]. IEEE Internet of Things Journal, 2024, 11 (2): 2550- 2560
doi: 10.1109/JIOT.2023.3292374
|
|
|
| [5] |
余意, 李松, 王艳芬 车联网场景联合缓存及内容请求策略[J]. 高技术通讯, 2022, 32 (5): 502- 510 YU Yi, LI Song, WANG Yanfen Joint caching and content request strategy for Internet of vehicle[J]. Chinese High Technology Letters, 2022, 32 (5): 502- 510
doi: 10.3772/j.issn.1002-0470.2022.05.007
|
|
|
| [6] |
XU C, ZHANG P, XIA X, et al Digital-twin-assisted intelligent secure task offloading and caching in blockchain-based vehicular edge computing networks[J]. IEEE Internet of Things Journal, 2025, 12 (4): 4128- 4143
doi: 10.1109/JIOT.2024.3482870
|
|
|
| [7] |
雒江涛, 杨和平, 冉泳屹 基于参数化强化学习的车联网内容缓存和功率分配联合优化[J]. 电子与信息学报, 2023, 45 (7): 2476- 2483 LUO Jiangtao, YANG Heping, RAN Yongyi Joint optimization of content caching and power distribution for Internet of vehicles based on parametric reinforcement learning[J]. Journal of Electronics and Information Technology, 2023, 45 (7): 2476- 2483
doi: 10.11999/JEIT220857
|
|
|
| [8] |
崔亚平, 石宏吉, 吴大鹏, 等 内容新鲜度保障的车联网多智能体缓存分发策略[J]. 通信学报, 2025, 46 (1): 52- 66 CUI Yaping, SHI Hongji, WU Dapeng, et al Multi-agent caching distribution strategy for content freshness guarantee in IoV[J]. Journal on Communications, 2025, 46 (1): 52- 66
doi: 10.11959/j.issn.1000-436x.2025013
|
|
|
| [9] |
YU S, DAS A K, PARK Y RLBA-UAV: a robust and lightweight blockchain-based authentication and key agreement scheme for PUF-enabled UAVs[J]. IEEE Transactions on Intelligent Transportation Systems, 2024, 25 (12): 21697- 21708
doi: 10.1109/TITS.2024.3480029
|
|
|
| [10] |
VAEZI M, AZARI A, KHOSRAVIRAD S R, et al Cellular, wide-area, and non-terrestrial IoT: a survey on 5G advances and the road toward 6G[J]. IEEE Communications Surveys and Tutorials, 2022, 24 (2): 1117- 1174
doi: 10.1109/COMST.2022.3151028
|
|
|
| [11] |
LIN Z, LIN M, DE COLA T, et al Supporting IoT with rate-splitting multiple access in satellite and aerial-integrated networks[J]. IEEE Internet of Things Journal, 2021, 8 (14): 11123- 11134
doi: 10.1109/JIOT.2021.3051603
|
|
|
| [12] |
张天魁, 徐瑜, 刘元玮, 等 无人机辅助MEC系统: 架构、关键技术与未来挑战[J]. 电信科学, 2022, 38 (8): 3- 16 ZHANG Tiankui, XU Yu, LIU Yuanwei, et al UAV-assisted MEC systems: architecture, key technology, and future challenges[J]. Telecommunications Science, 2022, 38 (8): 3- 16
doi: 10.11959/j.issn.1000-0801.2022237
|
|
|
| [13] |
ARAF S, SAHA A S, KAZI S H, et al UAV assisted cooperative caching on network edge using multi-agent actor-critic reinforcement learning[J]. IEEE Transactions on Vehicular Technology, 2023, 72 (2): 2322- 2337
doi: 10.1109/TVT.2022.3209079
|
|
|
| [14] |
BAI J, ZHU S, CHEN Y, et al Joint optimization of caching and content delivery in air–ground cooperation environment[J]. IEEE Internet of Things Journal, 2025, 12 (5): 6029- 6045
doi: 10.1109/JIOT.2024.3490612
|
|
|
| [15] |
ZHAO M, ZHANG R, HE Z, et al Joint optimization of trajectory, offloading, caching, and migration for UAV-assisted MEC[J]. IEEE Transactions on Mobile Computing, 2025, 24 (3): 1981- 1998
doi: 10.1109/TMC.2024.3486995
|
|
|
| [16] |
YU G, WU J, LIU R, et al Joint cooperative caching and UAV trajectory optimization based on mobility prediction in the Internet of connected vehicles[J]. IEEE Transactions on Intelligent Transportation Systems, 2024, 25 (11): 17392- 17406
doi: 10.1109/TITS.2024.3429305
|
|
|
| [17] |
ISLAM S R, AVAZOV N, DOBRE O A, et al Power-domain non-orthogonal multiple access (NOMA) in 5G systems: potentials and challenges[J]. IEEE Communications Surveys and Tutorials, 2017, 19 (2): 721- 742
doi: 10.1109/COMST.2016.2621116
|
|
|
| [18] |
MURUGANATHAN S D, LIN X Q, MÄÄTTÄNEN H, et al An overview of 3GPP release-15 study on enhanced LTE support for connected drones[J]. IEEE Communications Standards Magazine, 2021, 5 (4): 140- 146
|
|
|
| [19] |
ZHANG H, HAN M, LIU X, et al Joint resource allocation and trajectory optimization in multi-cell UAV and sidelink heterogeneous networks[J]. IEEE Transactions on Wireless Communications, 2024, 23 (11): 16635- 16647
doi: 10.1109/TWC.2024.3445149
|
|
|
| [20] |
MAHANANDA I G E, YOVITA L V, NEGARA R M. Performance of homogeneous and heterogeneous cache policy for named data network [C]//Proceedings of the 10th International Conference on Information and Communication Technology. Bandung: IEEE, 2022: 120–123.
|
|
|
| [21] |
ROSSI D, ROSSINI G. Caching performance of content centric networks under multi-path routing (and more) [R]. Paris: Telecom ParisTech, 2011: 1-6.
|
|
|
| [22] |
VAN HASSELT H, GUEZ A, SILVER D. Deep reinforcement learning with double Q-learning [C]// Proceedings of the AAAI Conference on Artificial Intelligence. Palo Alto: AAAI Press, 2016: 2094-2100.
|
|
|
| [23] |
BEN BEZZIANE M, HASAN S, BRIK B, et al Game theory-based UAV-cloud for service selection architecture in flying ad hoc networks[J]. IEEE Open Journal of Vehicular Technology, 2024, 5: 1692- 1711
doi: 10.1109/OJVT.2024.3430818
|
|
|
|
