| Dynamic pricing model for expressway toll rates in connected traffic environment |
Xiancai JIANG( ),Xinyao HE,Xinyue ZHANG |
| College of Civil Engineering and Transportation, Northeast Forestry University, Harbin 150040, China |
|
|
|
Abstract Differentiated tolling at various time periods neglects issues related to traffic efficiency and operational safety, resulting in no fundamental improvement in the utilization efficiency of road resources. To address this gap, a dynamic pricing model for expressway toll rates (DPM-ET) was proposed within the context of connected transportation. Operational safety was characterized by the standard deviation of vehicle speed, while traffic efficiency was reflected through vehicle speed along with vehicle platoon dynamics. Single-factor pricing models were constructed separately, then integrated with pricing to develop a multi-factor dynamic toll rate model. To enhance expressway resource utilization efficiency, Stackelberg price game theory was used to encourage optimized driving behavior, maintain stable and uniform speeds, and improve traffic flow safety. Simulation results show that compared to the benchmark scheme, DPM-ET improves the average lane speed by 2.01%-6.74% and speed stability by 5.22%, and achieves a maximum platooning rate of 0.9. Compared to similar pricing schemes, DPM-ET improves the value of optimal speed difference (VoOSD) by 4.68-5.37 times, speed stability by 21.17%, and the average lane speed by 5.22%-11.05%. DPM-ET achieves its optimal applicability when the platoon mileage weight is 0.7, the platoon size coefficient is 0.6, the reward coefficient is 0.8, the exponential decay rate coefficient is 0.67, and the maximum standard deviation pricing factor is 3.2.
|
|
Received: 16 September 2025
Published: 06 May 2026
|
|
|
| Fund: 黑龙江省自然科学基金资助项目(PL2024E012). |
网联环境下高速公路收费费率动态定价模型
时段差异化收费方式忽略了通行效率与运行安全问题,未使道路资源利用效率得到根本提升. 为此以网联交通为背景,提出高速公路收费费率的动态定价模型(DPM-ET). 以车速标准差刻画运行安全,车速及车辆编队体现通行效率,分别构建单因子定价模型、联合定价的多因子动态费率模型. 以提升高速公路道路资源利用效率为目标,采用斯塔克尔伯格价格博弈驱动驾驶者优化驾驶行为,保持车速平稳、统一,提升高速公路交通流的运行安全. 仿真结果表明,DPM-ET相较于基准方案,车道平均速度提升了2.01%~6.74%,速度稳定性提升了5.22%,编队率最高达到0.9. DPM-ET相较于同类定价方案,最优速差异价值(VoOSD)效果提升了4.68~5.37倍,速度稳定性提升了21.17%,车道平均速度提升了5.22%~11.05%. 当编队里程权重参数为0.7、编队规模定价系数为0.6、奖励系数为0.8、指数衰减速率系数为0.67、标准差定价因子上限为3.2时,DPM-ET处于最佳适用状态.
关键词:
智能交通,
动态定价,
收费费率,
斯塔克尔伯格博弈,
高速公路
|
|
| [1] |
QI X, JIANG Z, ZHANG J Low-carbon joint dispatch of integrated energy systems based on differentiated dynamic pricing mechanisms[J]. International Journal of Electrical Power and Energy Systems, 2024, 156: 109774
doi: 10.1016/j.ijepes.2023.109774
|
|
|
| [2] |
KONISHI H, MUN S I Carpooling and congestion pricing: HOV and HOT lanes[J]. Regional Science and Urban Economics, 2010, 40 (4): 173- 186
doi: 10.1016/j.regsciurbeco.2010.03.009
|
|
|
| [3] |
ZONG F, ZENG M, LI Y X Congestion pricing for sustainable urban transportation systems considering carbon emissions and travel habits[J]. Sustainable Cities and Society, 2024, 101: 105198
doi: 10.1016/j.scs.2024.105198
|
|
|
| [4] |
闫晟煜, 赵佳琪, 尤文博, 等 高速公路货车差异化通行费折扣的双层规划模型[J]. 清华大学学报: 自然科学版, 2025, 65 (7): 1347- 1358 YAN Shengyu, ZHAO Jiaqi, YOU Wenbo, et al Bi-level programming model for differentiated toll discounts for expressway trucks[J]. Journal of Tsinghua University: Science and Technology, 2025, 65 (7): 1347- 1358
doi: 10.16511/j.cnki.qhdxxb.2025.21.022
|
|
|
| [5] |
张惠玲, 王靖帆, 曹一铄, 等. 基于效益-费用的高速公路货车差异化收费双层优化建模[EB/OL]. (2025−04−08)[2025−05−29]. https://doi.org/10.13229/j.cnki.jdxbgxb.20241380.
|
|
|
| [6] |
陈晓昕 基于降本增效的高速公路差异化收费讨论[J]. 中国产经, 2025, (14): 84- 86 CHEN Xiaoxin Discussion on differential tolling for expressway based on cost reduction and efficiency improvement[J]. Chinese Industry and Economy, 2025, (14): 84- 86
|
|
|
| [7] |
JI A, RAMEZANI M, LEVINSON D Pricing lane changes[J]. Transportation Research Part C: Emerging Technologies, 2023, 149: 104062
doi: 10.1016/j.trc.2023.104062
|
|
|
| [8] |
LIN D, LI L, JABARI S E Pay to change lanes: a cooperative lane-changing strategy for connected/automated driving[J]. Transportation Research Part C: Emerging Technologies, 2019, 105: 550- 564
doi: 10.1016/j.trc.2019.06.006
|
|
|
| [9] |
SÁNCHEZ J A, MELENDI D, GARCÍA R, et al Distributed and collaborative system to improve traffic conditions using fuzzy logic and V2X communications[J]. Vehicular Communications, 2024, 47: 100746
doi: 10.1016/j.vehcom.2024.100746
|
|
|
| [10] |
HALL J D Pareto improvements from Lexus Lanes: the effects of pricing a portion of the lanes on congested highways[J]. Journal of Public Economics, 2018, 158: 113- 125
doi: 10.1016/j.jpubeco.2018.01.003
|
|
|
| [11] |
ABUZWIDAH M, ABDEL-ATY M Assessing the impact of express lanes on traffic safety of freeways[J]. Accident Analysis and Prevention, 2024, 207: 107718
doi: 10.1016/j.aap.2024.107718
|
|
|
| [12] |
FARIAS A V, ZHU S, MARDAN A An overview of dynamic pricing toll roads in the United States: pricing algorithms, operation strategies, equity concerns, and funding mechanism[J]. Case Studies on Transport Policy, 2024, 17: 101226
doi: 10.1016/j.cstp.2024.101226
|
|
|
| [13] |
LOMBARDI C, ANNASWAMY A M, PICADO-SANTOS L Dealing with a multiple access congested suburban freeway using a dynamic toll pricing approach[J]. Transportation Research Procedia, 2023, 72: 791- 798
doi: 10.1016/j.trpro.2023.11.469
|
|
|
| [14] |
武奇生, 席筱利, 王秋才 计重收费数据处理与费率模拟[J]. 交通运输工程与信息学报, 2008, 6 (2): 26- 30 WU Qisheng, XI Xiaoli, WANG Qiucai Data processing and rate simulating of loading-based toll collection[J]. Journal of Transportation Engineering and Information, 2008, 6 (2): 26- 30
doi: 10.3969/j.issn.1672-4747.2008.02.005
|
|
|
| [15] |
任英伟, 陆键, 吴守荣, 等 高速公路可变收费评价指标体系[J]. 交通运输工程与信息学报, 2009, 7 (1): 17- 21 REN Yingwei, LU Jian, WU Shourong, et al Variable pricing evaluation and the evaluation index system of freeway[J]. Journal of Transportation Engineering and Information, 2009, 7 (1): 17- 21
doi: 10.3969/j.issn.1672-4747.2009.01.004
|
|
|
| [16] |
LAVAL J A, CHO H W, MUÑOZ J C, et al Real-time congestion pricing strategies for toll facilities[J]. Transportation Research Part B: Methodological, 2015, 71: 19- 31
doi: 10.1016/j.trb.2014.09.015
|
|
|
| [17] |
LOU Y, YIN Y, LAVAL J A Optimal dynamic pricing strategies for high-occupancy/toll lanes[J]. Transportation Research Part C: Emerging Technologies, 2011, 19 (1): 64- 74
doi: 10.1016/j.trc.2010.03.008
|
|
|
| [18] |
LIU A, ZHONG S, SUN D, et al Joint optimal pricing strategy of shared autonomous vehicles and road congestion pricing: a regional accessibility perspective[J]. Cities, 2024, 146: 104742
doi: 10.1016/j.cities.2023.104742
|
|
|
| [19] |
GENSER A, KOUVELAS A Dynamic optimal congestion pricing in multi-region urban networks by application of a Multi-Layer-Neural network[J]. Transportation Research Part C: Emerging Technologies, 2022, 134: 103485
doi: 10.1016/j.trc.2021.103485
|
|
|
| [20] |
JIN J, ZHU X, WU B, et al A dynamic and deadline-oriented road pricing mechanism for urban traffic management[J]. Tsinghua Science and Technology, 2022, 27 (1): 91- 102
doi: 10.26599/tst.2020.9010062
|
|
|
| [21] |
KANG Q, JING J, WAN Q, et al Modeling and optimization of toll lane selection for connected and automated vehicles at toll plazas[J]. Physica A: Statistical Mechanics and Its Applications, 2024, 636: 129565
doi: 10.1016/j.physa.2024.129565
|
|
|
| [22] |
中华人民共和国国务院. 中华人民共和国道路交通安全法实施条例 [EB/OL]. (2017−10−07) [2026−02−07]. https://flk.npc.gov.cn/detail?id=ff8080816f3cbb3c016f40f566c10e23.
|
|
|
| [23] |
KONG D, SUN L, CHEN Y Traffic dynamics around freeway merging area with mixed conventional vehicles and connected and autonomous vehicles[J]. International Journal of Modern Physics C, 2022, 33 (10): 2250128
doi: 10.1142/S0129183122501285
|
|
|
| [24] |
KONG D, ZHANG X, WANG M, et al Modeling bounded rationality in discretionary lane-changing with the cumulative prospect theory[J]. Transportation Letters, 2025, 17 (10): 1785- 1800
doi: 10.1080/19427867.2025.2495940
|
|
|
| [25] |
LIU C, ZHANG C, YU C, et al Joint optimization of longitudinal and lateral locations of autonomous-vehicle-dedicated lanes on expressways[J]. IEEE Transactions on Intelligent Transportation Systems, 2024, 25 (1): 430- 442
doi: 10.1109/TITS.2023.3306792
|
|
|
| [26] |
TEODOROVIĆ D, EDARA P A real-time road pricing system: the case of a two-link parallel network[J]. Computers and Operations Research, 2007, 34 (1): 2- 27
doi: 10.1016/j.cor.2005.02.041
|
|
|
|
