| Civil Engineering |
|
|
|
|
| Large eddy simulation of wind load on low-rise buildings subjected to downburst |
Zhi-song WANG1,2( ),Jun DENG1,Zhi-yuan FANG1,Yuan-yuan CHEN1 |
1. College of Civil Engineering, Chongqing University, Chongqing 400045, China
2. Key Laboratory of New Technology for Construction of Cities in Mountain Area, Chongqing University, Chongqing 400045, China |
|
|
|
Abstract The large eddy simulation method was used to study the wind load characteristics of low-rise buildings under the action of unsteady thunderstorms. The following aspects were analyzed to study the influence on the wind load of the building in different development stages of the downburst: the radial position of the building, the roof slope and the wind direction angle, etc. Results show that there are significant differences in wind load effect at different development stages. When the first ring vortex generated by the airflow hitting the ground blows over the building, the wind load of the building is the most unfavorable. While the building is in different radial positions, the transient wind pressure caused by the ring vortex passing through the building is quite different from that caused by the steady downburst at the same position. The slope of roof has less influence on the distribution of wind pressure coefficient in the windward roof, but great influence on that in the windward side roof. When the slope of the roof increases, the wind pressure coefficient of the windward roof gradually changes from negative value to positive value. The wind pressure coefficient for the corner of the windward front of the building is obviously affected by the wind direction angle. In the tested condition, the influence is most significant when the wind direction angle is 45°.
|
|
Received: 02 March 2019
Published: 05 March 2020
|
|
|
下击暴流作用下低矮建筑风荷载大涡模拟
采用大涡模拟方法，研究非稳态雷暴风作用下低矮建筑的风荷载特征，分析下击暴流的不同发展阶段中建筑物所在的径向位置、屋面坡度和风向角等参数对建筑风荷载的影响. 结果表明：下击暴流各发展阶段风荷载效应差异显著，当气流冲击地面后形成的首个环形涡掠过建筑时，建筑表面风荷载最大；当建筑物处于不同径向位置时，环涡经过建筑物形成的瞬态风压与同样位置处稳态射流作用下的风压差异较大；屋面坡度对迎风面风压系数分布影响较小，但对迎风侧屋面风压系数分布的影响非常显著，随着屋面坡度的增大，迎风屋面风压系数由负值逐渐变为正值；建筑物迎风前沿角部区域的风压系数受风向角的影响较为明显，在所测试的工况中，风向角为45°时影响最为显著.
关键词：
下击暴流,
大涡模拟,
低矮建筑,
风荷载,
环形涡
|
|
| [1] |
HJELMFELT M R Structure and life cycle of microburst outflows observed in Colorado[J]. Journal of Applied Meteorology, 1988, 27 (8): 900- 927
doi: 10.1175/1520-0450(1988)027<0900:SALCOM>2.0.CO;2
|
|
|
| [2] |
FUJITA T T. Manual of downburst identification for project NIMROD [R]. SMRP Research Paper 156, University of Chicago, 104[NTISPB-286048], 1978.
|
|
|
| [3] |
MUNICH R E. Topics GEO natural catastrophes 2009 Analyses, assessment, positions (US VERSION) [R]. Munich RE, 2009.
|
|
|
| [4] |
MCCARTHY J, WILSON J W, FUJITA T T The joint airport weather studies project[J]. Bulletin of the American Meteorological Society, 2013, 63 (1): 15- 22
|
|
|
| [5] |
FUJITA T T. Objectives, operations, and results of project NIMROD [C] // Proceedings of 11th Conference on Severe Local Storms. Kansas: AMS, 1979: 259-266.
|
|
|
| [6] |
FUJITA T T. The downburst: microburst and macroburst report of projects NIMROD and JAWS [M]. Chicago: University of Chicago, 1985.
|
|
|
| [7] |
HOLMES J D. Physical modelling of thunderstorm downdrafts by wind tunnel jet [C] // Proceedings of the second AWES Workshop. Melbourne: AWES, 1992: 29-32.
|
|
|
| [8] |
CASSAR R. Simulation of a thunderstorm downdraft by a wind tunnel jet [R]. [S. l.]: Summer Vacation Report, DBCE 92/22(M）CSIRO, 1992.
|
|
|
| [9] |
LUO X Y, ZHANG C, XIONG S S, et al Numerical study of the flow fields in downburst with consideration[J]. Civil Engineering Journal, 2018, 4 (8): 1783
doi: 10.28991/cej-03091114
|
|
|
| [10] |
SENGUPTA A, SARKAR P P, RAJAGOPALAN G. Numerical and physical simulation of thunderstorm downdraft winds and their effects on buildings [C] // Proceedings of the First American Conference in Wind Engineering. Carolina: SC, 2001.
|
|
|
| [11] |
SENGUPTA A, SARKAR P P Experimental measurement and numerical simulation of an impinging jet with application to thunderstorm microburst winds[J]. Journal of Wind Engineering and Industrial Aerodynamics, 2008, 96 (3): 345- 365
doi: 10.1016/j.jweia.2007.09.001
|
|
|
| [12] |
LETCHFORD C W, CHAY M T Pressure distributions on a cube in a simulated thunderstorm downburst-Part A: stationary downburst observations[J]. Journal of Wind Engineering and Industrial Aerodynamics, 2002, 90 (7): 711- 732
doi: 10.1016/S0167-6105(02)00158-7
|
|
|
| [13] |
汤卓, 王兆勇, 卓士梅, 等 雷暴冲击风作用下双坡屋面风压分布[J]. 东南大学学报: 自然科学版, 2014, 44 (1): 168- 172
TANG Zhuo, WANG Zhao-yong, ZHOU Shi-mei, et al Wind pressure distribution of double slope roofs under thunderstorm impact wind[J]. Journal of Southeast University: Natural Science Edition, 2014, 44 (1): 168- 172
|
|
|
| [14] |
ZHANG Y, HU H, SARKAR P P Comparison of microburst-wind loads on low-rise structures of various geometric shapes[J]. Journal of Wind Engineering and Industrial Aerodynamics, 2014, 133: 181- 190
doi: 10.1016/j.jweia.2014.06.012
|
|
|
| [15] |
陈勇, 崔碧琪, 彭志伟, 等 球壳型屋盖在冲击风作用下的抗风设计参数及CFD分析[J]. 空气动力学学报, 2012, 30 (4): 456- 463
CHEN Yong, CUI Bi-qi, PENG Zhi-wei, et al Wind-resistant design parameters and CFD analysis of spherical shell roof under impact wind[J]. Acta Aerodynamica Sinica, 2012, 30 (4): 456- 463
doi: 10.3969/j.issn.0258-1825.2012.04.006
|
|
|
| [16] |
GELETA T N, ELSHAER A, MELAKU A, et al. Computational wind load evaluation of low-rise buildings with complex roofs using LES [C] // The 7th International Symposium on Computational Wind Engineering. Seoul: [s. n.], 2018 .
|
|
|
| [17] |
ZHANG Y, SARKAR P P, HU H An experimental study of flow fields and wind loads on gable-roof building models in microburst-like wind[J]. Experiments in Fluids, 2013, 54 (5): 1511
doi: 10.1007/s00348-013-1511-9
|
|
|
| [18] |
JUBAYER C, ELATAR A, HANGAN H. Pressure distributions on a low-rise building in a laboratory simulated downburst [C] // Proceedings of the 8th International Colloquium on Bluff Body Aerodynamics and Applications. Boston: [s. n.], 2016.
|
|
|
| [19] |
LETCHFORD C W, CHAY M T Pressure distributions on a cube in a simulated thunderstorm downburst. part B: moving downburst observations[J]. Journal of Wind Engineering and Industrial Aerodynamics, 2002, 90 (7): 733- 753
doi: 10.1016/S0167-6105(02)00163-0
|
|
|
| [20] |
HAINES M, TAYLOR I Numerical investigation of the flow field around low rise buildings due to a downburst event using Large Eddy Simulation[J]. Journal of Wind Engineering and Industrial Aerodynamics, 2018, 172: 12- 30
doi: 10.1016/j.jweia.2017.10.028
|
|
|
| [21] |
JESSON M, STERLING M, LETCHFORD C, et al Aerodynamic forces on generic buildings subject to transient, downburst-type winds[J]. Journal of Wind Engineering and Industrial Aerodynamics, 2015, 137: 58- 68
doi: 10.1016/j.jweia.2014.12.003
|
|
|
| [22] |
LETCHFORD C W, ILLIDGE G. Turbulence and topographic effects in simulated thunderstorm downdrafts by wind tunnel jet [C] // Proceedings of the Tenth International Conference on Wind Engineering, Denmark: [s. n.], 1999: 1907-1912.
|
|
|
| [23] |
WOOD G S, KWORK K C S, MOTTERAMB N A, et al Physical and numerical modeling of thunder-storm downbursts[J]. Journal of Wind Engineering and Industrial Aerodynamics, 2001, 89 (6): 535- 552
doi: 10.1016/S0167-6105(00)00090-8
|
|
|
|
