| Dual terminal differential improved recognition algorithm for car PEPS system |
Kai LIU1( ),Xiao-jun JI1,*(),Zhong-hua ZHAO1,Yi-wen CAO1,Jian YANG2,Xiao-feng PANG2 |
1. School of Electronic, Information and Electrical Engineering, Shanghai Jiao Tong University, Shanghai 200240, China
2. Technology Center of SAIC Motor, Shanghai 201800, China |
|
|
|
Abstract A differential K-nearest neighbor positioning algorithm based on dual terminals was designed aiming at the need for high-precision identification technology of Smartphone-based car passive entry and passive start (PEPS) system. The recognition results of the dual-terminal algorithm and the typical single-terminal algorithm were merged to improve the robustness and accuracy of the recognition algorithm through the improved Dempster-Shafer evidence theory. The accuracy of the internal and external state recognition of the terminal car was improved by 10% in the experimental scene by using the fusion algorithm. The error distance near the window was reduced from 20 cm to 5 cm in the vicinity of the window in which the conventional positioning algorithm was prone to misjudgment.
|
|
Received: 28 September 2019
Published: 28 October 2020
|
|
|
|
Corresponding Authors:
Xiao-jun JI
E-mail: 1148035619@sjtu.edu.cn;jxj127@sjtu.edu.cn
|
用于轿车PEPS系统的双终端差分改进识别算法
针对基于智能手机的汽车无钥匙进入和启动系统（PEPS）车内外高精度辨识技术需求，设计基于双终端的差分K近邻定位算法. 通过改进的Dempster-Shafer证据理论，将双终端算法与典型单终端算法的辨识结果进行融合，提升识别算法的鲁棒性与准确性. 与传统的K近邻和概率分布法相比，融合算法在实验场景中对终端车内外状态的辨识准确率提升10%. 在传统定位算法易出现误判的车窗附近范围内，将误差距离从距车窗20 cm缩小到距车窗5 cm.
关键词：
无钥匙进入与启动系统(PEPS),
接收信号强度,
位置指纹,
K近邻法,
差分,
Dempster-Shafer证据理论
|
|
| [1] |
BAHL P, PADMANABHAN V N. RADAR: an in-building RF-based user location and tracking system [C]// 19th Annual Joint Conference of the IEEE Computer and Communications Societies. Tel Aviv: IEEE, 2000: 775-784.
|
|
|
| [2] |
李华亮. WLAN环境下的室内定位算法研究[D]. 长春: 吉林大学, 2016.
LI Hua-liang. Research on indoor location algorithm in WLAN [D]. Changchun: Jilin University, 2016.
|
|
|
| [3] |
KARANI R, DHOTE S, KHANDURI N, et al. Implementation and design issues for using Bluetooth low energy in passive keyless entry systems [C]// 2016 IEEE Annual India Conference. Bangalore: IEEE, 2016: 1-6.
|
|
|
| [4] |
KARLSSON E, LAGERBIELKE A. Demonstrator development for phone as a key based on Bluetooth low energy [D]. Link?ping: Link?ping University, 2017.
|
|
|
| [5] |
全祯业. PEPS系统的安全与可靠性研究[D]. 贵阳: 贵州大学, 2016.
QUAN Zhen-ye. Research on the safety and reliability of PEPS system [D]. Guiyang: Guizhou University, 2016.
|
|
|
| [6] |
SHIN B, LEE J H, LEE T, et al. Enhanced weighted K-nearest neighbor algorithm for indoor Wi-Fi positioning systems [C]// International Conference on Computing Technology and Information Management. Seoul: IEEE, 2012: 574-577.
|
|
|
| [7] |
XIE Y, WANG Y, NALLANATHAN A, et al An improved K-nearest-neighbor indoor localization method based on Spearman distance[J]. IEEE Signal Processing Letters, 2016, 23 (3): 351- 355
doi: 10.1109/LSP.2016.2519607
|
|
|
| [8] |
ZHANG A, YUAN Y, WU Q, et al Wireless localization based on RSSI fingerprint feature vector[J]. International Journal of Distributed Sensor Networks, 2015, (9): 1- 7
|
|
|
| [9] |
PEI L, CHEN R, LIU J, et al. Inquiry-based Bluetooth indoor positioning via RSSI probability distributions [C]// International Conference on Advances in Satellite and Space Communications. Athens: IEEE, 2010: 151-156.
|
|
|
| [10] |
陈丽娜. WLAN位置指纹室内定位关键技术研究[D]. 上海: 华东师范大学, 2014.
CHEN Li-na. Research on major technology of using WLAN and fingerprint for indoor positioning [D]. Shanghai: East China Normal University, 2014.
|
|
|
| [11] |
CHEN L Bayesian fusion for indoor positioning using Bluetooth fingerprints[J]. Wireless Personal Communications, 2013, 70 (4): 1735- 1745
doi: 10.1007/s11277-012-0777-1
|
|
|
| [12] |
GELMINI S, STRADA S, TANELLI M, et al. Analysis and development of a novel algorithm for the in-vehicle hand-usage of a smartphone [C] // IEEE International Conference on Systems, Man, and Cybernetics. Miyazaki: IEEE, 2018: 1239-1244.
|
|
|
| [13] |
REN Qing-yu. On the potential of geomagnetism-aided vehicle in-out detection using BLE RSS [C]// 第38届中国控制会议论文集(3). 广州: 上海系统科学出版社, 2019: 6.
|
|
|
| [14] |
KING T, KOPF S, HAENSELMANN T, et al. COMPASS: a probabilistic indoor positioning system based on 802.11 and digital compasses [C]// ACM Workshop on Wireless Network Testbeds, Experimental Evaluation and Characterization. California: ACM, 2006: 34-40.
|
|
|
| [15] |
DEMPSTER A P Upper and lower probabilities induced by a multivalued mapping[J]. Annals of Mathematical Statistics, 1967, 38 (2): 325- 339
doi: 10.1214/aoms/1177698950
|
|
|
| [16] |
SHAFER G A. Mathematical theory of evidence [M]. Princeton: Princeton University Press, 1976.
|
|
|
| [17] |
ZADEH L A Review of Shafer’s a mathematical theory of evidence[J]. AI Magazine, 1984, 5 (3): 81- 83
|
|
|
| [18] |
LIU W Analyzing the degree of conflict among belief functions[J]. Artificial Intelligence, 2006, 170 (11): 909- 924
doi: 10.1016/j.artint.2006.05.002
|
|
|
| [19] |
YONG D, DONG W, QI L I, et al A new method to analyze evidence conflict[J]. Control Theory and Applications, 2011, 28 (6): 839- 844
|
|
|
| [20] |
WANG D, Li Q, JIANG W, et al New method to combine conflict evidence based on pignistic probability distance[J]. Infrared and Laser Engineering, 2009, 38 (1): 149- 154
|
|
|
| [21] |
张明华. 基于WLAN的室内定位技术研究[D]. 上海: 上海交通大学, 2009.
ZHANG Ming-hua. Study on WLAN based indoor location estimation technology [D]. Shanghai: Shanghai Jiaotong University, 2009.
|
|
|
|
