Extracting hand articulations from monocular depth images using curvature scale space descriptors
Shao-fan WANG,Chun LI,De-hui KONG,Bao-cai YIN
Front. Inform. Technol. Electron. Eng.    2016, 17 (1): 41-54.   DOI: 10.1631/FITEE.1500126
Abstract   HTML   PDF (2840KB)

We propose a framework of hand articulation detection from a monocular depth image using curvature scale space (CSS) descriptors. We extract the hand contour from an input depth image, and obtain the fingertips and finger-valleys of the contour using the local extrema of a modified CSS map of the contour. Then we recover the undetected fingertips according to the local change of depths of points in the interior of the contour. Compared with traditional appearance-based approaches using either angle detectors or convex hull detectors, the modified CSS descriptor extracts the fingertips and finger-valleys more precisely since it is more robust to noisy or corrupted data; moreover, the local extrema of depths recover the fingertips of bending fingers well while traditional appearance-based approaches hardly work without matching models of hands. Experimental results show that our method captures the hand articulations more precisely compared with three state-of-the-art appearance-based approaches.




View image in article
Fig. 1 A flowchart of extracting the hand contour and palm center: (a) finding a point on the hand; (b) selecting a rectangular neighborhood; (c) segmenting the hand part; (d) extracting the contour of the hand part; (e) computing the maximum inscribed circle of the contour; (f) removing additional contour points
Extracts from the Article
We illustrate the main procedure for extracting the contour of the hand and the palm center in Fig. 1, which includes six steps: (1) find a hand point on the depth image using the function hand_points of openNI; (2) select a rectangular neighborhood of the point; (3) segment the hand part from the patch using a threshold of difference of the depth value with respect to the hand point; (4) extract the contour of the hand using find_contours of openCV; (5) compute the maximum inscribed circle of the contour and take its center as the palm center; (6) remove additional contour points which belong to the wrist, and arrange the remaining contour points from the thumb to the little finger (i.e., in the clockwise/counterclockwise direction for the left/right hand).
