| Effect of pilot-main interval on 2-Methylfuran/ Diesel RCCI combustion |
Chen HUANG1,2( ),Wan-zhi ZHANG1,2,Ting-ting ZHANG1,2,*(),Gui-zhi MU1,2,Qian ZHU1,2,Song LI3 |
1. School of Mechanical and Electronic Engineering, Shandong Agricultural University, Taian 271018, China
2. Shandong Provincial Engineering Laboratory of Agricultural Equipment Intelligence, Taian 271028, China
3. School of Mechanical Engineering, Shaanxi University of Technology, Hanzhong 723001, China |
|
|
|
Abstract Based on the optical engine test platform, the effects of pre-injection and main injection strategies on the combustion characteristics and soot emissions of 2-methylfuran (MF)/diesel reactivity controlled compression ignition (RCCI) were explored under the condition of MF accounting for 50% of the total calorific value of single cycle injection by using high-speed camera technology and in-cylinder combustion analysis technology. Results show that, in the pilot-main interval (crank angle between main and pilot injection) of less than 40°, with the advance of the pre-injection time, the pre-injected diesel and MF mix more evenly, the low-temperature heat release is no longer limited to the cylinder center, and the atomization and evaporation of the main injection diesel are better. The uniform mixture makes the flame change from diffusion combustion to the coexistence of premixed and diffusion combustion, which makes the combustion more sufficient and the combustion rate faster. The high soot area with KL factor above 1.5 in the combustion chamber is reduced, and the soot generation rate and yield are significantly reduced. The main injection time has a great influence on the flame development in the early stage of combustion. As the main injection time is delayed, the ignition delay period and combustion duration are shortened, the combustion phase is delayed, the low temperature heat release in the early stage of combustion increases, the flame development speed slows down, and the soot formation increases in the later stage.
|
|
Received: 09 October 2022
Published: 31 August 2023
|
|
|
| Fund: 山东省薯类产业技术体系农业机械岗位专家资助项目（SDAIT-16-10）；河南省重点研发与推广专项（科技攻关）资助项目（232102220087） |
|
Corresponding Authors:
Ting-ting ZHANG
E-mail: hc676869@163.com;zhangtingting_sdau@163.com
|
主预喷间隔对2-甲基呋喃/柴油RCCI燃烧的影响
基于光学发动机试验台架，结合缸内燃烧分析技术与高速摄影技术，探究在2-甲基呋喃（MF）占单次循环喷油量总热值50%的条件下，预喷和主喷2次喷油策略对MF/柴油反应性控制压缩点火（RCCI）的燃烧特性与碳烟排放的影响. 结果表明：当主预喷间隔（主预喷之间的曲轴转角）小于40°时，随着预喷时刻的提前，预喷柴油与MF混合更均匀，低温放热不再局限于气缸中心，且主喷柴油雾化蒸发更好；混合气均匀使火焰由扩散燃烧主导向预混与扩散燃烧并存转变，燃烧更充分，速率更快；燃烧室内KL因子大于1.5的高碳烟区域减少，碳烟生成速率与产量明显降低. 主喷时刻对燃烧初期火焰发展影响较大，随着主喷时刻向上止点推迟，滞燃期与燃烧持期缩短，燃烧相位推迟，燃烧前期低温放热增多，火焰发展速度变慢，后期碳烟生成增多.
关键词：
2-甲基呋喃,
双燃料发动机,
双色法,
碳烟,
光学发动机
|
|
| [1] |
ROMM J The car and fuel of the future[J]. Energy Policy, 2006, 34 (17): 2609- 2614
doi: 10.1016/j.enpol.2005.06.025
|
|
|
| [2] |
SPLITTER D A, HANSON R M, KOKJOHN S L, et al. Improving engine performance by optimizing fuel reactivity with a dual fuel PCCI strategy [C]// THIESEL 2010 Conference on Thermo-and Fluid Dynamic Processes in Diesel Engines. Valencia: THIESEL, 2010.
|
|
|
| [3] |
冉兴旺, 刘海峰, 唐青龙, 等 直喷燃料特性对高比例预混压燃燃烧的影响[J]. 燃烧科学与技术, 2018, 24 (4): 354- 360
RAN Xing-wang, LIU Hai-feng, TANG Qing-long, et al Effects of direct-injection fuel properties on highly premixed charge compression ignition combustion process[J]. Journal of Combustion Science and Technology, 2018, 24 (4): 354- 360
|
|
|
| [4] |
刘海峰, 文铭升, 杨智, 等 发动机缸内自燃着火与火焰传播的调控[J]. 内燃机学报, 2020, 38 (3): 200- 209
LIU Hai-feng, WEN Ming-sheng, YANG Zhi, et al Optical diagnostics on combustion mode between auto-ignition and flame propagation in engines[J]. Transactions of CSICE, 2020, 38 (3): 200- 209
|
|
|
| [5] |
KOKJOHN S, HANSON R, SPLITTER D, et al Fuel reactivity controlled compression ignition (RCCI) combustion in light- and heavy-duty engines[J]. SAE International Journal of Engines, 2011, 4 (1): 360- 374
doi: 10.4271/2011-01-0357
|
|
|
| [6] |
KALONG M, HONGMANOROM P, RATCHAHAT S, et al Hydrogen-free hydrogenation of furfural to furfuryl alcohol and 2-methylfuran over Ni and Co-promoted Cu/γ-Al2O3 catalysts [J]. Fuel Processing Technology, 2021, 214: 106721
doi: 10.1016/j.fuproc.2020.106721
|
|
|
| [7] |
汪梨超, 陈碧娴, 周阔 生物质基糠醛加氢脱氧制2-甲基呋喃非均相催化剂的研究进展[J]. 广东化工, 2020, 47 (11): 82- 86
WANG Li-chao, CHEN Bi-xian, ZHOU Kuo Progress in the heterogeneous catalyst for hydrodeoxygenation of biomass-based furfural into 2-Methylfuran[J]. Guangdong Chemical, 2020, 47 (11): 82- 86
|
|
|
| [8] |
ZHANG Q C, CHEN G S, ZHENG Z Q, et al Combustion and emissions of 2, 5-dimethylfuran addition on a diesel engine with low temperature combustion[J]. Fuel, 2013, 103: 730- 735
doi: 10.1016/j.fuel.2012.08.045
|
|
|
| [9] |
ZHENG Z Q, WANG X F, ZHONG X F, et al Experimental study on the combustion and emissions fueling biodiesel/n-butanol, biodiesel/ethanol and biodiesel / 2, 5-dimethylfuran on a diesel engine[J]. Energy, 2016, 115: 539- 549
doi: 10.1016/j.energy.2016.09.054
|
|
|
| [10] |
HOANG A T, PHAM V V 2-Methylfuran (MF) as a potential biofuel: a thorough review on the production path-way from biomass, combustion progress, and application in engines[J]. Renewable and Sustainable Energy Reviews, 2021, 148: 111265
doi: 10.1016/j.rser.2021.111265
|
|
|
| [11] |
XIAO H L, ZENG P F, LI Z Z, et al Combustion performance and emissions of 2-methylfuran diesel blends in a diesel engine[J]. Fuel, 2016, 175: 157- 163
doi: 10.1016/j.fuel.2016.02.006
|
|
|
| [12] |
XIAO H L, WANG R, ZENG P F, et al Effects of pilot injection on combustion and emissions characteristics using 2-methylfuran/diesel blends in a diesel engine[J]. Thermal Science, 2020, 24 (1): 1- 11
|
|
|
| [13] |
XIAO H L, YANG X L, HOU B B, et al Combustion performance and pollutant emissions analysis of a diesel engine fueled with biodiesel and its blend with 2-methylfuran[J]. Fuel, 2019, 237: 1050- 1056
doi: 10.1016/j.fuel.2018.09.146
|
|
|
| [14] |
LIU H Y, OLALERE R F, WANG C M, et al Combustion characteristics and engine performance of 2-methylfuran compared to gasoline and ethanol in a direct injection spark ignition engine[J]. Fuel, 2021, 299: 120825
doi: 10.1016/j.fuel.2021.120825
|
|
|
| [15] |
WANG C M, XU H M, DANIEL R, et al Combustion characteristics and emissions of 2-methylfuran compared to 2, 5-dimethylfuran, gasoline and ethanol in a DISI engine[J]. Fuel, 2013, 103: 200- 211
doi: 10.1016/j.fuel.2012.05.043
|
|
|
| [16] |
秦天. 基于双色法定容弹内柴油喷雾燃烧温度与碳烟场研究 [D]. 武汉: 华中科技大学, 2019.
QIN Tian. Study on temperature and soot field for diesel spray combustion in constant volume bomb based on two-color [D]. Wuhan: Huazhong University of Science and Technology, 2019.
|
|
|
| [17] |
BLIGNAUT C Effects of the injection timing on spray and combustion characteristics in a spray-guided DISI engine under lean-stratified operation[J]. Fuel, 2013, 107: 225- 235
doi: 10.1016/j.fuel.2013.01.019
|
|
|
| [18] |
LEE C F, PANG Y, WU H, et al The optical investigation of hydrogen enrichment effects on combustion and soot emission characteristics of CNG/diesel dual-fuel engine[J]. Fuel, 2020, 280: 118639
doi: 10.1016/j.fuel.2020.118639
|
|
|
| [19] |
田辛, 何邦全, 王建昕, 等 用双色法研究进气道喷射乙醇柴油引燃时的燃烧过程[J]. 内燃机学报, 2004, 22 (1): 39- 44
TIAN Xin, HE Bang-quan, WANG Jian-xin, et al Research on the combustion process of ethanol injected in the intake port ignited by diesel fuel by means of two-color method[J]. Transactions of CSICE, 2004, 22 (1): 39- 44
|
|
|
| [20] |
PAYRI F, PASTOR J V, GARCIA J M, et al Contribution to the application of two-colour imaging to diesel combustion[J]. Measurement Science and Technology, 2007, 18 (8): 2579
doi: 10.1088/0957-0233/18/8/034
|
|
|
| [21] |
王丽雯, 王建昕, 何旭 双色法在内燃机燃烧诊断中的应用[J]. 小型内燃机与摩托车, 2007, 36 (3): 26- 29
WANG Li-wen, WANG Jian-xin, HE Xu Application of two-color method in combustion diagnosis of IC engine[J]. Small Internal Combustion Engines and Motorcycle, 2007, 36 (3): 26- 29
|
|
|
| [22] |
何旭, 徐一凡, 王路, 等 柴油温度对燃烧火焰温度和碳烟生成的影响[J]. 内燃机学报, 2021, 39 (2): 97- 105
HE Xu, XU Yi-fan, WANG Lu, et al Influence of diesel temperature on combustion flame temperature and soot formation characteristics[J]. Transactions of CSICE, 2021, 39 (2): 97- 105
|
|
|
| [23] |
马帅营. 汽油/柴油双燃料高预混合低温燃烧技术应用基础研究 [D]. 天津: 天津大学, 2013.
MA Shuai-ying. Applied background research on low temperature combustion technology of highly premixed charge combustion fuelled with gasoline/diesel dual-fuel [D]. Tianjin: Tianjin University, 2013.
|
|
|
| [24] |
ZHANG M, DERAFSHZAN S, RICHTER M, et al Effects of different injection strategies on ignition and combustion characteristics in an optical PPC engine[J]. Energy, 2020, 203: 117901
doi: 10.1016/j.energy.2020.117901
|
|
|
| [25] |
曹嘉伟, 何志霞, 玄铁民, 等 柴油燃烧火焰中碳烟生成的特性试验[J]. 内燃机学报, 2017, 35 (6): 516- 522
CAO Jia-wei, HE Zhi-xia, XUAN Tie-min, et al Experimental study of soot formation in the diesel combustion flame[J]. Transactions of CSICE, 2017, 35 (6): 516- 522
|
|
|
|
