| Ultra-high cycle fatigue life prediction method for aero engine impeller |
Yan-zhong WANG1,2( ),Kai YANG1,Rong-hua QI1,Yan-yan CHEN1,Fei LI1,Hao GAO2 |
1. School of Mechanical Engineering and Automation, Beihang University, Beijing 100191, China
2. College of Mechanical and Electrical Engineering, Sanming University, Sanming 365004, China |
|
|
|
Abstract The stress and fatigue life of impeller of special equipment under different load conditions were analyzed in order to predict the ultra-high cycle fatigue life of aero-engine impellers. A finite element model of the impeller was established, and the stress changes of impeller blade which bears centrifugal and aerodynamic loads were simulated and analyzed. The results of further revise stress were achieved by considering surface state of impeller blade. An ultra-high cycle fatigue life prediction model for TC4 was established based on the dislocation dipole model and related theory. The service life for aero engine impeller was predicted by using the revised data and the prediction models. The service life predicted by existing model and the proposed model were compared. Results indicated that the changing of service life predicted by these two models showed the same trend in both low cycle and high cycle ranges. The problem of predicting the fatigue life of the impeller can be solved more effectively by the proposed model, and the predicted data was closer to the tested data. The surface state of the impeller had a greater impact on the prediction of fatigue life, because the predicted data was closer to the tested ones when considering the surface state.
|
|
Received: 12 March 2018
Published: 28 March 2019
|
|
|
航空发动机叶轮超高周疲劳寿命预测方法
为了预测航空发动机叶轮的超高周疲劳寿命,以某型叶轮为研究对象，研究叶轮叶片在不同载荷状态下的应力和疲劳寿命. 建立叶轮的有限元模型，通过仿真分析叶轮叶片在离心、气动载荷作用下的应力变化情况；考虑叶轮叶片的表面状态，修正应力结果；基于位错偶极子模型及相关理论，建立TC4材料的超高周寿命预测模型；结合修正交变应力和寿命预测模型，实现了航空发动机叶轮的寿命预测. 对比分析现有模型和该模型下的寿命预测结果，结果表明：2种模型在低、高周范围内预测寿命的变化趋势一致；利用该模型有效解决了叶轮疲劳寿命的预测问题，预测值较贴近测试寿命；叶轮表面状态对疲劳寿命的预测结果影响较大，因为考虑了表面状态，寿命预测结果更贴近测试寿命值.
关键词：
航空发动机叶轮,
位错偶极子,
超高周疲劳,
寿命预测,
表面状态
|
|
